17-meter hybrid crawler platform
SPR 170-H
The SPR 170-H crawler articulated boom lift is the ideal choice for compact and demanding applications at height. With a working height of up to 17 meters and a platform height of 15 meters, you can reliably reach even hard-to-reach areas. The 7.50-meter lateral outreach makes it particularly flexible for assembly work and applications in tight spaces.
The work basket measures 0.70 x 1.30 meters and carries up to 230 kilograms – enough for one person with tools and materials.
A hybrid drive with electric and diesel engines ensures maximum flexibility: emission-free operation indoors , powerful use outdoors. The white-coated rubber tracks are gentle on floors and leave no marks—ideal for sensitive surfaces in halls or public buildings.
With compact transport dimensions of 4.53 x 0.80 x 1.99 meters (L x W x H), the SPR 170-H fits through almost any standard door. Even narrow passages and gaps can be negotiated with ease. The support area of 2.90 x 2.90 meters ensures secure footing – even on uneven terrain. With a dead weight of 2,190 kg, the gradeability is 29% .
A special feature is the low floor load on the supports of only 2.50 kg/cm² (equivalent to 25,000 kg/m²). This makes the platform suitable for use on suspended ceilings, industrial floors, or other load-bearing surfaces.
Whether for interior work, facade maintenance or on rough terrain – the SPR 170-H is a compact, all-terrain and reliable solution for professional access at heights.
If you would like to rent a 17-meter crawler platform from BIBERGER, you will receive one of the following devices:
